8 Channel 4K SDI Hybrid DVR

$1,400.00


Available | Within 7-14 Days | Free Delivery


This 8 channel Hybrid SDI Recorder Features:



8 Channel SDI Hybrid DVR Series, Comes with 6 TB hard Drive, But is also a AHD EX-SDI, HD_SDI, TVI, CVI, 960H, IP 7brid DVR, RTSP dual recording, P2P Service, Transcoding Playback, Push Notification, Dual LAN Port, UHD display & FHD Spot, Two way audio. Can use up to 8 megapixel cameras.


Add Extra Hard Drive Storage

Comes with 6 Terabyte Add 12 , 18 or 24 terabyte of CCTV hard Drive

Description

8 Channel 4K SDI Hybrid DVR Recorder for medium installs



This 8 Channel SDI Hybrid 4k DVR is the next level up in Analogue CCTV being a Hybrid AHD EX-SDI, HD_SDI, TVI, CVI, 960H, IP Recorder with 4K 8 megapixel resolution capability. At CCTVAustralia we have researched AHD DVR’s and have found this 8 channel DVR to be reliable in software and giving long lasting performance that is needed if you are serious about quality . This DVR is ideal for a 8ch dvr security system and come with HDMI & VGA inputs for High Definition LCD  screen viewing. This DVR is for Domestic & Small Business purpose.



Webclient for Safari for MAC PC is not available CMS Software needs to be installed on the MAC PC to view through the network & watch live on MAC PC computer. CMS stands for Content Management Software which comes on the Disc for the DVR to be loaded on to your computer. This software lets you view multiple locations at once or just one location if needed. To view the higher Megapixel resolution of hd sdi recorders you must use SDI cameras with SDI DVR’s otherwise you will not get the full resolution of this technology which is 2 Megapixel resolution.



This DVR also has the capability to have a Audio device connected and can be networked using Internet Explorer and Mac to view over the internet. This DVR also has mobile phone monitoring and can be connected to a LCD screen via HDMI. This DVR does not have a Spot output for viewing another LCD screens in different areas our DVR`s will give you this. This DVR has a 2 Year warranty.



Specifications

8 Channel HD-SDI DVR
Compression H.264(High Profile)
Operating System Embedded Linux
OS Firmware Linux OS in Flash Memory
Signal Format NTSC or PAL (Auto Selected)
Video Input 8 Channel HD-SDI (1080p, 1080i, 720p Manual Selection)
Mixed Input Possible
Video Output 1 VGA / 1 HDMI (Max 1920x1080p)
Max. Recording Rate 240fps @ 1080p
Audio Input 8 Input
Audio Output 1 Output (RCA Jack)
Audio Codec ADPCM (16bit)
Ethernet 10 / 100 / 1000 Mbps Ethernet (RJ-45)
Network Bandwidth Control 56 Kbps ~ Unlimited
Dual Network Streaming Selectable
Alarm Input 8 Input
Alarm Output 8 (TTL) / 2 (Relay)
Master Alarm 1
Search(Date/Time, Calendar, Event) Yes
User Interface(GUI / Control Device) Yes / Keypad, Mouse, PTZ Control, Remote Controller
Archive File Format EXE(Video Clip)/ AVI(Video Clip) / JPEG(Still Image)
NTP Server Yes
GMT Time Zone Yes
Auto DST Yes
Recording Quality Super / High / Standard
Recording Mode Schedule / Alarm / Motion / Emergency
Pre-Alarm Recording Up to 10 Min. / User Programmable
Motion Detection Yes (22 X 15)
Playback Control X1, X2, X4, X8, X16, X32, X64, Extreme
PTZ Control RS-485/422 Terminal Block
POS / ATM Support Up to 4 Channels Over USB
Multi Language Arabic / Chinese (Simplified) / Chinese (Traditional) / Croatian / Czech /
Danish / English / French / German / Italian / Japanese / Korean / Persian /
Polish / Portuguese / Russian / Spanish / Thai / Turkish
Mobile Viewer iPad / iPhone / Android
e-SATA 1 Port
USB Interface 4 (Front : 2, Rear : 2)
Primary Storage 4 HDD, up to 12TB
Clip Copy Storage Internal DVD-RW, USB Memory
Dimension (WxHxD) 430mm x 88mm x 430mm
Power 100 ~ 240VAC
Operating Temperature (+)5˚C ~ (+)40˚C
Operating Humidity 90% or less
