| Accelerometer | Forward facing camera 1080P CMOS Sensor | |
| In Car 1080P CMOS Sensor | |
| Camera view angle (Diagonal) | Forward facing camera view angle approx.130° | |
| In car camera view angle approx.120° | |
| Voltage | (a). Active mode: 12V Input, 0.75A | |
| (b). Sleep mode: DC12V input, 2.5mA | |
| (c). Voltage input: DC9V-DC36V | |
| Operating Temperature | -20℃ ~70℃ | |
| Storage | (a). Class 10 micro-SDHC /SDXC Card 8GB or above | |
| recommended. | |
| Otherwise, the recording cannot proceed smoothly | |
| (b). Micro SD slot support 512GB storage max. | |
| Dual storage slot support 1TB | |
| Recording type | Forward facing camera resolution | |
| 1920×1080 up to 30fps @ NTSC & 25Fps @PAL | |
| In car camera resolution | |
| 1920×1080 up to 30fps @NTSC & 25fps @PAL | |
| Auto record when power up system; In car camera can | |
| be closed software. | |
| Record content | Image, date and time, sound, G-sensor, GPS | |
| Microphone | built in high sensitive microphone |
| Time Setting | Time calibration by GPS built in calendar clock takes over |
| if no GPS signal. |
| G-Sensor | Internal 3D G-Sensor Accelerometer |
| 4G LTE | (a). 4G network module on board |
| (network module compatibility with local network ) |
| (b). support Global Fleet management |
| WIFI | (a). Built in wifi module (2.4G HZ) |
| (b). Support wifi AP & P2P Mode |
| Output/input device | (a). VIDEO OUT：TV-Out |
| (1 Vp-p composite video output, 75 ohms) |
| (b). Force Record Button: For emergency recording. |
| (Trigger Flash LED) |
| (c). REC: Recording indicator |
| (Flash LED means SD Error) |
| (Lights on means recording) |
| (d). GPS: Recording indicator |
| (Flash LED means 3D positioning is not ready) |
| (Lights on means 3D already positioning) |
| (e). NET: NET indicator |
| (Flash LED means Wireless network is not ready) |
| (Lights on means wireless network already) |
| (f). WiFi：WiFi indicator |
| (Flash LED means WIFI network is not ready) |
| (Lights on means WIFI network already) |
| Accessory | (a). 2 Meter power cable |
| (b). Bracket holder with 3M adhesive |
| (c). wrench |
| (d). Product CD |
| Explanation | (a). GPS positioning accuracy may be affected by the |
| installation position, sun-screen or weather condition. |
| (b). Automotive front insulation paper with metal |
| components may lead to GPS cannot position. |
| (c). In car camera built in day night auto switch IR cut. , |
| the performance will be effect by light and other |
| environment factor effect. |
| (d). After SD card format by device or PC player, all |
| showing 80.5MB storage space under Windows system, |
| other storage space as hidden files, user have to play |
| video records by professional player that offer by |
| manufacturer. |
| The restore SD card also have to use the manufacturer |
| player refer to format/restore memory card chapter. |
| Notice | (a). For ensure clarity of video, install device in the wiper |
| washable area. |
| (b). Before using the memory disk, please format the disk |
| first by the software player. If not, device will automatically |
| erase all data in the memory disk before recording, |
| then recording as default setting. |
| (c). Device wire installation diagram. During the wire |
| installation, avoid set wire on top above GPS, please set |
| wire through device Rear hole to vehicle ceiling to get |
| better GPS signal. |
| (d). Devices video output normally divided into two systems: |
| NTSC or PAL. Ensure using suitable system according |
| to different devices and monitors. |
| (e). Memory card has life limit. For ensure it working |
| correctly, please test the memory card on PC Player |
| regularly. |
| Optional | 8GB Class 10 above micro SD Card |
| 4G module (EC25 series) |
